An air quality monitoring station is a facility specifically designed for real-time monitoring and recording of various pollutant concentrations and meteorological parameters in the air. It can accurately measure meteorological parameters such as PM2.5, PM10, sulfur dioxide, nitrogen dioxide, ozone, and carbon monoxide, providing data for environmental departments

1. Air quality monitoring station Introduction
 The WX-WZ01 micro ambient air quality monitoring system consists of various environmental sensors, data acquisition master control, wireless communication equipment, power supply equipment, and software platform. It can be used to measure various ambient air data such as PM2.5, PM10, CO, SO2, NO2, O3, TVOC, etc. The system adopts a modular design, and can flexibly add or reduce corresponding modules and sensors for various environmental elements according to different regional environmental conditions, and can be combined arbitrarily to meet various user needs conveniently and quickly. Data is uploaded to the cloud management platform via wireless/GPRS, and the big data intelligent dynamic analysis, timely alarm, and precise source locking are used to strengthen the supervision system.
 II. Main technical parameters
 1. Monitoring factors: PM2.5, PM10, SO2, NO2, CO, O3, temperature, humidity
 2. Expandable monitoring factors: non-methane total hydrocarbons, benzene series, H2S, NH3, etc.
 3. Monitoring period: 60s
 4. Working environment: -20℃~70℃, 5%-95%RH
 5. Power supply: 12V/220V
 6. Communication method: GPRS, WiFi, 4G
 III. Technical features
 1. Modular design, configuration of any combination, convenient for setting different monitoring factors on demand, suitable for large-scale grid distribution;
 2. Pump-sucking sealed gas chamber, can be calibrated on-site with standard gas;
 3. Equipped with zero gas calibration module;
 4. Four-electrode high-precision imported sensor and imported PID sensor are selected;
 5. PM10 and PM2.5 mass concentrations can be measured simultaneously without replacing the sampling cutter;
 6. The circuit adopts industrial-grade embedded processor, which is suitable for harsh outdoor environment, and the working environment temperature range is (-40—70)℃;
 7. Dynamic heating control is used for particle sampling to eliminate the influence of water mist on the measurement data;
 8. The sampling flow of particulate matter and gaseous pollutants uses an electronic flow meter to measure the flow rate and dynamic PID flow control. Long-life sampling power system, quiet and efficient;
 9. Industrial-grade data transmission module is selected, and data transmission is stable and reliable;
 10. The system adopts dual-channel communication mode to achieve communication in extreme cases and ensure data continuity;
 11. Modular design, high-reliability CAN bus communication is adopted between modules, and automotive electronic communication protocol is adopted to ensure system stability;
 12. Not only can remote data transmission be realized, but also system status information can be read remotely, and remote control can be realized, instrument parameters can be modified remotely, and faults can be diagnosed;
 13. The terminal device can remotely upgrade the terminal application through the FTP server to achieve remote maintenance, ensuring that users can use the latest application and update system functions in time;
 14. Optional meteorological five-parameter tester;
 15. Optional IP cameras with various parameters can ensure night and line-of-sight shooting requirements, can automatically capture, and can also be viewed by users in real time;
 16. On-site real-time data display: the terminal instrument displays data once every 5 seconds;
 17. The optional data service platform can display minute, hourly average, and daily average. Report analysis function, can generate daily
 reports, monthly reports, annual reports, trend analysis and other functions. Support multi-point display on the same screen, support mobile
 terminal data query, and can also push data to the display terminal;
 20. Various installation methods can be selected according to the site conditions: bracket installation, hanging rod installation and other methods, any installation method is firm and reliable, and can withstand instantaneous 12-level wind force.
